Номер |
Название |
|
|
| * |
31NB-60133 |
BUCKET CYL ASSY |
 |
| * |
31NB-60134 |
BUCKET CYL ASSY |
| * |
31NB-60134 |
BUCKET CYL ASSY |
| *-1 |
31Y1-24641 |
BUCKET CYL SUB ASSY |
| * |
31NB-60133 |
BUCKET CYL ASSY |
| * |
31NB-60134 |
BUCKET CYL ASSY |
| 2 |
31Y1-24721 |
ROD ASSY |
| * |
31NB-61130 |
BUCKET CYL ASSY |
| *-1 |
31Y1-24640 |
BUCKET CYL SUB ASSY |
| *-1 |
31Y1-24641 |
BUCKET CYL SUB ASSY |
| *-1 |
31Y1-24640 |
BUCKET CYL SUB ASSY |
| *-1 |
31Y1-24641 |
BUCKET CYL SUB ASSY |
| *-1 |
31Y1-24642 |
BUCKET CYL SUB ASSY |
| 1 |
31Y1-24680 |
TUBE ASSY |
| 2 |
31Y1-24720 |
ROD ASSY |
| 2 |
31Y1-24721 |
ROD ASSY |
| 2 |
31Y1-24720 |
ROD ASSY |
| 2 |
31Y1-24721 |
ROD ASSY |
| 2 |
31Y1-37130 |
ROD ASSY |
| 3 |
31Y1-24750 |
GLAND |
| 3 |
31Y1-24750 |
GLAND |
| 3 |
31Y1-37430 |
GLAND |
| 4 |
S732-110045 |
BUSHING-DD2 |
| 5 |
Y191-117000 |
RING-SNAP |
| K6 |
Y220-110011 |
SEAL-ROD |
| K7 |
Y180-110020 |
RING-BACK UP |
| 21 |
31YC-61144 |
NUT-LOCK |
| K8 |
Y240-110013 |
RING-BUFFER |
| K9 |
Y110-110011 |
WIPER-DUST |
| 10 |
Y190-126000 |
RING-SNAP |
| 30 |
S651-810002 |
NIPPLE-GREASE |
| 31 |
S114-080204 |
SCREW-SET |
| K11 |
S631-150004 |
O-RING |
| K12 |
S641-150003 |
RING-BACK UP |
| 13 |
31YC-23050 |
RING-CUSHION |
| 13 |
31YC-23050 |
RING-CUSHION |
| 13 |
31YC-26105 |
RING-CUSHION |
| 14 |
31Y1-08172 |
PISTON |
| 14 |
31Y1-08172 |
PISTON |
| 14 |
31Y1-33095 |
PISTON |
| K15 |
S632-095004 |
O-RING |
| K15 |
S632-095004 |
O-RING |
| K15 |
S632-085004 |
O-RING |
| K16 |
S642-095003 |
RING-BACK UP |
| K16 |
S642-095003 |
RING-BACK UP |
| K16 |
S642-085003 |
RING-BACK UP |
| K17 |
Y420-160000 |
SEAL-PISTON |
| K18 |
Y310-160200 |
RING-WEAR |
| K19 |
Y440-160002 |
RING-DUST |
| 20 |
31YC-66081 |
WASHER-LOCK |
| 20 |
31YC-66081 |
WASHER-LOCK |
| 21 |
31YC-61143 |
NUT-LOCK |
| 21 |
31YC-61144 |
NUT-LOCK |
| 21 |
31YC-61143 |
NUT-LOCK |
| 21 |
31YC-61144 |
NUT-LOCK |
| 21 |
31YC-68060 |
NUT-LOCK |
| 22 |
S109-200904 |
BOLT-SOCKET |
| 23 |
31YC-11401 |
BUSHING-PIN |
| K24 |
Y000-100100 |
SEAL-DUST |
| 30 |
S651-810002 |
NIPPLE-GREASE |
| 31 |
S114-080204 |
SCREW-SET |
| 31 |
S114-080204 |
SCREW-SET |
| 31 |
S114-100164 |
SCREW-SET |
| 25 |
31Y1-22120 |
BAND ASSY |
| 25-1 |
31Y1-09380 |
BAND SUB ASSY |
| 25-2 |
31YC-31240 |
BAND |
| 25-3 |
S015-120452 |
BOLT-HEX |
| 25-4 |
S411-120002 |
WASHER-SPRING |
| 25-5 |
31YC-37050 |
CLAMP-PIPE |
| 25-6 |
S011-100452 |
BOLT-HEX |
| 25-7 |
S411-100002 |
WASHER-SPRING |
| 26 |
31Y1-24650 |
PIPE ASSY-R |
| 27 |
31Y1-24660 |
PIPE ASSY-B |
| K28 |
Y171-024004 |
O-RING |
| 29 |
S107-120604 |
BOLT-SOCKET |
| K |
31Y1-24670 |
SEAL KIT |
| K |
31Y1-24670 |
SEAL KIT |
| K |
31Y1-24671 |
SEAL KIT |
|
|
