Номер |
Название |
|
|
| * |
31N9-50121 |
CYLINDER ASS'Y,LH |
|
| * |
31N9-50122 |
BOOM CYL/D ASS'Y |
| * |
31N9-50111 |
CYLINDER ASS'Y,RH |
| * |
31N9-50112 |
BOOM CYL/D ASS'Y |
| *-1 |
31Y1-19041 |
BOOM CYLINDER SUB |
| *-1 |
31Y1-19042 |
CYLINDER W/O PIPE |
| 1 |
31Y1-20930 |
TUBE ASSY |
| 2 |
31Y1-20980 |
ROD ASSY |
| 2 |
31Y1-20981 |
ROD ASS'Y |
| 3 |
31Y1-21010 |
GLAND |
| 4 |
S732-105045 |
DD2 BUSH |
| 5 |
Y191-112000 |
RING-SNAP |
| K6 |
Y220-105011 |
SEAL-ROD |
| K7 |
Y180-105120 |
RING-BACK UP |
| K8 |
Y240-105013 |
RING-BUFFER |
| K9 |
Y110-105011 |
WIPER-DUST |
| 10 |
Y190-121000 |
RING-SNAP |
| K11 |
S631-140004 |
O-RING |
| K12 |
S641-140003 |
RING-BACK UP |
| 13 |
31YC-23060 |
RING-CUSHION |
| 14 |
31Y1-08780 |
PISTON |
| K15 |
S632-090004 |
O-RING |
| K16 |
S642-090003 |
RING-BACK UP |
| K17 |
Y420-150000 |
SEAL-PISTON |
| K18 |
Y310-150100 |
RING-WEAR |
| K19 |
Y440-150000 |
RING-DUST |
| 20 |
31YC-66071 |
WASHER-LOCK |
| 21 |
31YC-61153 |
NUT-LOCK |
| 21 |
31YC-61154 |
NUT-LOCK |
| 22 |
S109-200904 |
BOLT-SOCKET |
| 28 |
31YC-11405 |
BUSHING |
| 29 |
Y000-100100 |
SEAL-DUST |
| 30 |
S114-080184 |
SCREW-SET,HEX SOC HDLESS |
| 23 |
31Y1-21021 |
BAND ASS'Y,LH |
| 23 |
31Y1-21031 |
BAND ASS'Y,RH |
| 23-1 |
31Y1-21041 |
BAND SUB ASS'Y,LH |
| 23-1 |
31Y1-21051 |
BAND SUB ASS'Y,RH |
| 23-2 |
31YC-32240 |
BAND |
| 23-3 |
S015-120452 |
BOLT-HEX |
| 23-4 |
S411-120002 |
WASHER-SPRING |
| 23-5 |
S071-023430 |
U-BOLT |
| 23-6 |
S201-101002 |
NUT-HEX |
| 23-7 |
S411-100002 |
WASHER-SPRING |
| 24 |
31Y1-21061 |
PIPE ASS'Y-R,LH |
| 24 |
31Y1-21071 |
PIPE ASS'Y-R,RH |
| 25 |
31Y1-19171 |
PIPE ASSY-LH |
| 25 |
31Y1-19181 |
PIPE ASSY-RH |
| K26 |
Y171-024004 |
O-RING |
| 27 |
S107-120554 |
BOLT-SOCKET |
| K |
31Y1-21100 |
SEAL KIT |
|
|
