Номер |
Название |
|
|
| 1 |
21EN-32220 |
ACTUATOR-ACCEL |
 |
| 2 |
11N8-62160 |
BRACKET |
| 4 |
S035-082026 |
BOLT-W/WASHER |
| 5 |
S205-08100B |
NUT-HEX |
| 5 |
S275-08000B |
NUT-SELF LOCKING |
| 6 |
S411-080006 |
WASHER-SPRING |
| 7 |
S593-000902 |
CLIP-HARNESS |
| 7 |
S593-000802 |
CLIP-HARNESS |
| 8 |
11N8-66081 |
LEVER-THROTTLE |
| 9 |
S035-062026 |
BOLT-W/WASHER |
| 10 |
11N8-66021 |
LINK-ASSY |
| 10-1 |
11N8-66070 |
BRACKET-LINK |
| 10-2 |
11N8-66051 |
LEVER-ROD |
| 10-3 |
11N8-66060 |
LEVER-CABLE |
| 10-4 |
S461-200252 |
PIN-SPLIT |
| 10-5 |
S403-12100B |
WASHER-PLAIN |
| 11 |
11N8-66120 |
BKT-SUPPORT |
| 12 |
S037-102526 |
BOLT-W/WASHER |
| 13 |
11N8-66091 |
ROD ASSY |
| 14 |
S926-106000 |
END-ROD |
| 15 |
S501-060002 |
PIN-SELF LOCKING |
| 16 |
11N8-66130 |
CABLE |
| 17 |
S491-060202 |
PIN-CLEVIS |
| 18 |
11N8-66111 |
BKT-LINK ASSY |
| 18-1 |
11N8-66100 |
BRACKET-PEDAL |
| 18-2 |
11FA-10030 |
PIN |
| 18-3 |
S411-100006 |
WASHER-SPRING |
| 18-4 |
S205-10000B |
NUT-HEX |
| 18-5 |
11M8-60360 |
BELL CRANK |
| 18-6 |
11M8-60330 |
SPRING-RETURN |
| 18-7 |
S403-10200B |
WASHER-PLAIN |
| 18-8 |
P560-090002 |
RETAINING RING-E TYPE |
| 18-9 |
11N8-66151 |
ROD-ACCEL |
| 18-1 |
P560-050002 |
E-RING |
| 18-11 |
S403-06200B |
WASHER-PLAIN |
| 18-12 |
S461-250202 |
PIN-SPLIT |
| 19 |
S015-080806 |
BOLT-HEX |
| 20 |
11N8-66170 |
PEDAL ASSY |
| 21 |
11FA-10100 |
PIN |
| 22 |
11N8-66140 |
LOCKER |
| 22-1 |
11N8-66300 |
BASE-STOPPER |
| 22-2 |
11N8-66311 |
LEVER-LOCKER |
| 22-3 |
S295-100002 |
CAP NUT-DOMED |
| 22-4 |
S205-10100B |
NUT-HEX |
| 22-5 |
11S1-1002 |
WAHSER-CON SPRING |
| 22-6 |
S403-10100B |
WASHER-PLAIN |
| 23 |
S411-060006 |
WASHER-SPRING |
| 24 |
S275-06000B |
NUT-SELF LOCKING |
|
|
