Номер |
Название |
|
|
| 1 |
170403-00122 |
MOTOR,TRAVEL |
 |
| 2 |
410-00011 |
CYLINDER ASS`Y |
| 3 |
409-00033 |
PISTON & SHOE ASS`Y |
| 4 |
423-00081 |
VALVE CASING ASS`Y |
| 5 |
409-00034A |
TILTING PISTON ASS`Y |
| 6 |
410207-00104 |
SPOOL;COUNTER BALANCE |
| 7 |
K9002261A |
SHAFT;DRIVE |
| 8 |
K9009896 |
BEARING;ROLLER |
| 9 |
109-00144 |
BEARING;NEEDLE |
| 10 |
S6500500 |
RING;STOP |
| 11 |
408-00021 |
BUSH |
| 12 |
129-00096 |
SPRING;CYLINDER |
| 13 |
412-00034 |
PLATE;SET |
| 14 |
K9009897 |
PLATE;SWASH |
| 15 |
110913-00162 |
CASE,SHAFT |
| 16 |
410127-00132 |
VALVE,RELIEF |
| 17 |
420-00195A |
VALVE,RELIEF |
| 18 |
420-00196 |
VALVE;REDUCING |
| 19 |
430-00025 |
COVER |
| 20 |
114-00345 |
WASHER |
| 21 |
129-00097 |
SPRING;COUNTER BALANCE |
| 22 |
403-00005A |
COVER;COUNTER BALANCE |
| 23 |
S8010451 |
O-RING |
| 24 |
S2215561 |
BOLT;SOCKET M12X1.75X45 |
| 25 |
S2228671 |
BOLT;SOCKET |
| 26 |
S2227661 |
BOLT;SOCKET |
| 27 |
S6510900 |
RING;SNAP |
| 28 |
2181-1116D10 |
PLUG |
| 29 |
2181-1950D3 |
PLUG |
| 30 |
1.180-00159 |
O-RING |
| 31 |
S8000181 |
O-RING |
| 32 |
2180-8002A |
SEAL;OIL |
| 33 |
148-00019 |
BALL;PIVOT |
| 34 |
S8000161 |
O-RING |
| 35 |
424-00086 |
SPOOL;TILTING |
| 36 |
129-00098 |
SPRING;TILTING |
| 37 |
429-00021 |
SEAT |
| 38 |
416-00012 |
STOPPER |
| 39 |
S6250132 |
BALL;STEEL |
| 40 |
415-00032 |
ORIFICE |
| 41 |
430219-00013 |
ORIFICE |
| 42 |
415-00033 |
ORIFICE |
| 43 |
430219-00012 |
ORIFICE |
| 44 |
S8000111 |
O-RING |
| 45 |
2181-1116D2 |
PLUG |
| 46 |
2181-1950D1 |
PLUG |
| 47 |
2181-1890D2 |
PLUG |
| 48 |
S8000111 |
O-RING |
| 49 |
2181-1890D3 |
PLUG |
| 50 |
S8000141 |
O-RING |
| 51 |
452-00023 |
PISTON;BRAKE |
| 52 |
452-00023A |
PISTON,BRAKE |
| 53 |
415-00034 |
ORIFICE |
| 54 |
415-00035 |
ORIFICE |
| 55 |
129-00062 |
SPRING;BRAKE |
| 56 |
129-00062 |
SPRING;BRAKE |
| 57 |
2180-1217D156 |
O-RING |
| 58 |
1.180-00161 |
O-RING |
| 59 |
412-00036 |
PLATE;SEPARATOR |
| 60 |
412-00037 |
PLATE;FRICTION |
| 61 |
2401-9264KT |
SEAL KIT;MOTOR |
|
|
