Номер |
Название |
|
|
| 1 |
K1006550 |
MAIN PUMP |
 |
| 2 |
K1006550A |
PUMP;MAIN |
| 3 |
K1006550B |
MAIN PUMP |
| 4 |
K1006550C |
MAIN PUMP |
| 5 |
400914-00393 |
MAIN PUMP |
| 6 |
1.405-00055 |
SHAFT;DRIVE(F) |
| 7 |
1.405-00057 |
SHAFT;DRIVE(R) |
| 8 |
1.403-00004 |
GEAR;1st |
| 9 |
1.109-00111 |
BEARING;ROLLER |
| 10 |
1.109-00055 |
BEARING;NEEDLE |
| 11 |
2.109-00228 |
SPACER;BEARING |
| 12 |
1.451-00065 |
CYLINDER ASS`Y(R) |
| 13 |
K9006419 |
CYLINDER ASS`Y(R) |
| 14 |
1.451-00062 |
CYLINDER ASS`Y(L) |
| 15 |
K9006420 |
CYLINDER ASS`Y(L) |
| 16 |
K9006418 |
PISTON ASSY |
| 17 |
1.412-00098 |
PLATE;SET |
| 18 |
1.110-00101 |
BUSH |
| 19 |
1.131-00131 |
SPRING;CYLINDER |
| 20 |
1.412-00110 |
PLATE;SHOE |
| 21 |
K9001176 |
SWASH PLATE ASS`Y |
| 22 |
K9001177 |
PLATE;SWASH |
| 23 |
2.408-00088 |
BUSH;TILTING |
| 24 |
K9001178 |
PROPORTIONAL REDUCING VALVE |
| 25 |
K9001179 |
E.P.P.R VALVE |
| 26 |
2180-1217D13 |
O-RING |
| 27 |
2180-1217D14 |
O-RING |
| 28 |
2180-1217D15 |
O-RING |
| 29 |
1.402-00097 |
CASING;VALVE |
| 30 |
S2205861 |
SCREW |
| 31 |
2181-1950D1 |
PLUG |
| 32 |
2.181-00214 |
PLUG |
| 33 |
S8000115 |
O-RING |
| 34 |
S8000165 |
O-RING |
| 35 |
K9001180 |
SUPPORT |
| 36 |
1.430-00213 |
COVER;SEAL(F) |
| 37 |
2.423-00114 |
CASING;PUMP |
| 38 |
K9001181 |
BLOCK;VALVE |
| 39 |
K9001182 |
COVER;SEAL(F) |
| 40 |
S2229071 |
BOLT;SOCKET |
| 41 |
S2208871 |
BOLT;SOCKET |
| 42 |
S2211861 |
BOLT;SOCKET M10X1.5X20 |
| 43 |
2181-1950D1 |
PLUG |
| 44 |
2181-1950D2 |
PLUG |
| 45 |
2181-1950D5 |
PLUG PF3/4 |
| 46 |
2.181-00214 |
PLUG |
| 47 |
1.123-00089 |
TILTING PIN ASS`Y |
| 48 |
1.123-00090 |
PIN;TILTING |
| 49 |
2.123-00154 |
PIN;FEED BACK |
| 50 |
1.409-00209 |
PISTON |
| 51 |
1.416-00020 |
STOPPER(L) |
| 52 |
1.416-00021 |
STOPPER(S) |
| 53 |
K9001183 |
CHECK VALVE ASS`Y(1) |
| 54 |
K9001184 |
SEAT |
| 55 |
K9001185 |
STOPPER;1 |
| 56 |
S6250132 |
BALL;STEEL |
| 57 |
K9001186 |
CHECK VALVE ASS`Y(2) |
| 58 |
K9001184 |
SEAT |
| 59 |
K9001187 |
STOPPER;1 |
| 60 |
S6250132 |
BALL;STEEL |
| 61 |
S8010355 |
O-RING |
| 62 |
S8010955 |
O-RING |
| 63 |
S8011455 |
O-RING |
| 64 |
S8000085 |
O-RING |
| 65 |
S8000115 |
O-RING |
| 66 |
S8000145 |
O-RING |
| 67 |
S8000245 |
O-RING |
| 68 |
S8000185 |
O-RING |
| 69 |
K9001188 |
SEAL;OIL |
| 70 |
401106-00108 |
SEAL,OIL |
| 71 |
S8060181 |
RING;BACKUP |
| 72 |
S8090350 |
RING;BACK-UP |
| 73 |
S4012931 |
NUT |
| 74 |
S4015130 |
NUT |
| 75 |
S6500400 |
RING;RETAINING |
| 76 |
2.123-00067 |
PIN;VALVE PLATE |
| 77 |
S5740870 |
PIN;SPRING |
| 78 |
S3140025 |
BOLT;EYE |
| 79 |
S3527906 |
SCREW |
| 80 |
1.120-00071 |
SCREW |
| 81 |
K9001195 |
SEAL KIT;PUMP |
| 82 |
401107-01044 |
SEAL KIT;PUMP |
|
|
